Pivot Studio Pattern Engine 1.40 for 3dsMax

图案引擎 (Pattern Engine) 是一款适用于 3ds Max 的脚本化工具，可以生成和编辑各种 3D 几何体类型，例如参数化图案、3D 拼贴、隔断、搁架、墙面艺术、室内装潢等等，比其他方法更快、更轻松。

主要特点：

用户友好界面：易于使用且结构清晰的界面。

灵活的图案自适应：图案对象可以生成并自适应为任何 2D 平面闭合形状。

多种阵列模式：可从网格、径向或随机阵列模式中选择。

丰富的形状库：超过 40 种可用作图案元素的原始形状。

三种分布模式：按权重、随机或表达式分布元素。

X 和 Y 表达式：控制每个元素沿 X 轴和 Y 轴的百分比。

每个元素的参数：调整深度、角度、比例、坡度、可见性等，以微调您的设计。

凹面模式：生成空心（凹面）物体，并将其与规则（凸面）物体混合。

轮廓模式：创建带轮廓或边框的物体，打造独特外观。

效果：该工具最强大的功能之一。使用四种效果类型（渐变、随机、表情和形状）将任何合适的值映射到图案上。您还可以使用各种混合模式混合效果，以获得更佳控制。

凹凸不平：对凸面物体应用“枕头”效果，可用于生成室内装饰形状。

阵列边框：从多个侧面偏移图案，并可选择显示边框。可用于在特定区域内构建图案。

局部对齐：当物体的比例小于 100% 时，可在局部空间内为每个物体提供不同的对齐选项。

材质 ID 模式：提供四种模式：固定、随机、按物体和表情。

内置预设：包含超过 200 个不同类别的现成预设。

立即保存：对图案对象的任何更改都会立即保存，方便您稍后重新访问和编辑。

预设管理：保存和加载预设，或从其他对象中选取预设。

要求

操作系统：Windows 10 或更高版本。

3ds Max 兼容性：3ds Max 2018 至 2025 版本。

互联网连接：激活许可证和随机许可证验证所需。

Pattern Engine is a scripted tool for 3ds Max that can generate and edit a variety of 3D geometry types—such as parametric patterns, 3D tiles, partitions, shelves, wall art, upholstery, and more—much faster and more easily than other approaches.

Key Features

User-Friendly Interface: An easy-to-use, well-organized interface.

Flexible Pattern Adaptation: Pattern objects can be generated and adapted to any 2D flat, closed shape.

Multiple Array Modes: Choose from Grid, Radial, or Random array modes.

Extensive Shape Library: Over 40 primitive shapes to use as pattern items.

Three Distribution Modes: Distribute items by Weight, Random, or Expression.

X and Y Expressions: Control the percentage of each item along the X and Y axes.

Per-Item Parameters: Adjust depth, angle, scale, slope, visibility, and more to fine-tune your designs.

Concave Mode: Generate hollow (concave) items and mix them with regular (convex) items.

Outline Mode: Create outlined or framed items for a unique look.

Effects: One of the tool’s most powerful features. Map any eligible value across the pattern with four effect types: Gradient, Random, Expression, and Shape. You can also blend effects using various blending modes for more control.

Bumpy Convex: Apply a “pillow” effect to convex items—useful for generating upholstery forms.

Array Borders: Offset the pattern from multiple sides with the option to display the border. Useful for framing patterns within a specific area.

Local Alignment: Different options for per-item alignment within local space when an item’s scale is under 100%.

Material ID Modes: Four modes are available—Fixed, Random, By Item, and Expression.

Built-In Presets: Over 200 ready-to-use presets in different categories are included.

Immediate Saving: Any changes to a pattern object are saved immediately, allowing you to revisit and edit them later.

Preset Management: Save and load presets, or pick a preset from another object.

Requirements

Operating System: Windows 10 or later.

3ds Max Compatibility: 3ds Max versions 2018 to 2025.

Internet Connection: Required for activating the license and for random license verification.
