CADintosh X macOS v8.9.2

CADintosh 是一款面向技术绘图员和设计师的高性能 2D CAD 程序。 您将受益于专业且经过深思熟虑的功能，满足您的所有设计需求。

工作流程改进与易用性优势

• 单窗口界面（无需额外工具窗口即可快速访问所有功能）

• 支持 Retina 显示屏

• 元素数量仅受可用内存限制

• 为每个绘图保存预设设置

主要功能：线条与工具

• 8 种笔，具有可自由定义的线宽和线条颜色

• 6 种线型：实线、虚线、点划线、双点划线、折线、短虚线

• 独立模式：线宽从 0.0 到 99.99 毫米，每个元素可指定不同的颜色和宽度（不兼容 HPGL）

• 提供用于线条、圆形、尺寸标注、剖面线、X 线等的功能

支持群组和图层

• 32,000 个群组

• 1,024 个图层

• 简单的图层管理

兼容性

• 导入和导出 DXF、HPGL、IGES 和 PDF

• 支持 Unicode

• 支持用于导入和导出符号的符号库

• 替代单位，例如英寸

• 原生运行于 macOS

系统要求
macOS 10.13 或更高版本
支持 Intel 和 Apple Silicon Mac

CADintosh is a high‑performance 2D CAD program for technical draftsmen and designers. You will benefit from professional and well‑thought‑out features for all your design requirements.

Workflow improvement and usability advantages

• Single‑window interface (quick access to all features without any additional tool windows)

• Retina display support

• The number of elements is limited only by your available memory

• Pre‑settings are saved for each drawing

Key features: Lines and tools

• 8 pens with freely definable line widths and line colors

• 6 line types: full line, dotted line, chain line, dotted line with two dots, zigzag line, short dotted line

• Individual mode: line widths from 0.0 to 99.99 mm, and each element can be designated a different color and width (not compatible with HPGL)

• Functions available for lines, circles, dimensioning, hatching, X‑lines, etc.

Support for groups and layers

• 32,000 groups

• 1,024 layers

• Simple layer management

Compatibility

• Import and export of DXF, HPGL, IGES, and PDF

• Unicode support

• Support for symbol libraries for importing and exporting symbols

• Alternative units, e.g., for inches

• Runs natively on macOS

System Requirements
macOS 10.13 or later
Supports Intel and Apple Silicon Macs
